Features：
>H.264/H.265 Video Compression
>Resolution 1080P-4MP, Dual Stream
>Motion Detection / Privacy Mask
>Mega Pixel Lens, True Day Night (ICR)
>Auto Day And Night, IR Distance 80M
>Compatible With Onvif/psia Standard
>Android, Apple Mobile Phone System
Application：
Applicable in the high definition required areas: finance, telecommunications, supermarkets, hotels, government, schools, airports, factories, public security, justice, and The Peace City, etc
|
 |
| |
| Model |
IPC-835H4MP |
IPC-835H2MP/H2M |
| Image Sensor |
1/2.5 " CMOS |
| Effective Pixels |
2592(H)X1520(V) |
1920 (H) *1080(V) |
| Min. Illumination |
0 Lux |
| Image Compression |
H.265/H.264 |
| Image Frame Rate |
4MP(2592*1520)25fPS |
1080P(1920*1080)25fPS |
| Bit Rate |
16K-16M |
| Users |
20 simultaneous users |
| Processors & OS |
GM8126 SoC ARM926 + H.264 Encoder |
| System |
Linux2.6.28 |
| Video Management Software |
NVS Client, Surveillance application for viewing
Easy view P2P software Active X control, SDK on VC++ |
| Supported Protocol |
TCP, UDP, IP, HTTP, DHCP, PPPoE, UPnP etc. |
| IR Light Number |
2pcs High Power Array LED |
| IR Distance |
80M |
| Lens |
16mm, 12mm,8mm,6mm,3.6mm Mega Pixel Focus Lens |
| Day Night |
Auto Day And Night |
| Input Voltage |
DC12V±10% |
| Current (ma) |
180mA (IR OFF) /1500mA (IR ON) |
| Power Consumption |
<2.5W (IR OFF) / 24W (IR ON) |
| Waterproof Level |
IP66 |
| Operating Conditions |
0℃-+45℃,20-80%RH (non-sondensing) |
|
|
|
